    High Stability Multilayer Ceramic Capacitor Mid Voltage 2.2uF 450V

    Ask Lasest Price
    Brand Name : WS
    Model Number : CKG57NX7T2W225MT009W
    Certification : SGS
    Price : Lowest
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 1000000pcs/day
    Delivery Time : 3-5 work days
    • Product Details
    • Company Profile

    High Stability Multilayer Ceramic Capacitor Mid Voltage 2.2uF 450V


    High Stability Multilayer Ceramic Capacitor Mid Voltage CKG57NX7T2W225MT009W 2.2uF 450V


    Features:
    • High-accuracy automatic mounting is facilitated through the maintenance of very precise
    dimensional tolerances.
    • Low residual inductance assures superior frequency characteristics.
    • Low stray capacitance ensures high conformity with
    nominal values, thereby simplifying the circuit design process.
    • Voltage rating of up to 630V
    • High mechanical strength
    • No polarity

    * Size : 2220/ 5750
    * Capacitance Range: 2.2UF
    * Voltage range: 450V

    * Capcitance Tolerance: +/-20%

    * RoHS Compliant, Lead free


    Applications:

    • Output bypass in power supply
    • Driver circuit in plasma display
    • Noise bypass in automotive
    • Other mid voltage applications etc...



    Nominal Capacitance (pF):
    The capacitance is expressed in three digit codes and in units of pico Farads(pF).

    The first and second digits identify the first and second significant figures of
    the capacitance. The third digit identifies the multiplier. R designates a decimal point.


    Capacitance Code Capacitance
    0R5 0.5pF
    010 1pF
    102 1,000pF (1nF)
    105 1,000,000pF (1μF)



    Dimension Size:

    ItemSize(mm)
    inchcmLWMetal Terminal Width
    222057506±0.505.00±0.501.60±0.30



    Payment and Shipping:


    1, Lead time about 3~5 days.
    2, Payment: T/T; Western union; Paypal .
    3, Shipping: by DHL, Fedex, TNT, UPS, EMS ect
