Large Current Low DCR Volume Thin WSCH8D Series SMD Power Inductor

FEATURES:

Various high power inductors are superior to be high saturation for surface mounting .

Inductance Range: 1.8uH - 100uH
Rated Current : 0.44A~7A(Max)

DCR : 0.016~0.56 Ω (Max)

Small, medium and high-quantity are available
-With wide frequency range
Low profile power inductor
Low DCR leaded power inductor

Resistance to electromagnetic interference,

Large permissible D.C. current and low D.C. resistance
PVC Sleeve protects the winding

Excellent thermal stability

Low profile
High saturation current

Magnetic shielded
SMT type

Operating temperature range: -25°C~+110°C with rated current
Storage temperature range: -25°C~+110°C
Large permissible D.C. current and low D.C. resistance

PART NUMBERING SYSTEM:
WSCH - 8D28 - 100 - K - R
(1 ) (2) (3) (4) (5)
1 Series Name
2 Dimensions
3 Inductance 1R0＝1.0uH.100＝10uH. 101＝100uH.
4 Tolerance J＝±5%, K＝±10%, L＝±15%, M＝±20%, P＝±25%, N＝±30%
5 Packing code R: Tape&Reel B: In Bulk

APPLICATIONS:
For smoothing circuit of DC-DC converter, as choke coil or chopper coil
Suitable for use in power lines of camcorder, LCD set, OA equipment,

notebook computer, PDA, -and small size communication equipment

Notebook
Inkjet printer
Copying machine

ADSL modem
Cellular phone
Display monitor

Video tape recorder
Video camera etc.
