Metallized Polypropylene / Polyester Film X2 Safety Capacitor Rohs Certification

Specifications:
1 Operating Temperature -40 C ~+100 C
2 Rated Voltage275VAC 50Hz --- 60Hz; 100V~2000V DC
3 Capacitance Range0.01μF---3.3 μF
4 Capacitance Tolerance: +/-10%, +/-20%
5 Insulation Resistance(meesued at 100+/-15VDC 60sec at 25)
C≤0.33UF IR≥35000M OHM C≥0.33UF IR≥1000M OHM
6 Dissipation Factor0.1% max (at 1KHz +25)
7 Testing Voltage1185VDC 60sec or 2000VDC 1sec
8 Dmensions(mm): MIN 13.0 X 11.0 X 5.0 X 10.0 (W x H x T x P)
MAX 42.0 X 32.0 X 18.0 X 37.5 (W x H x T x P)

Features:

1, Provides interference suppression, all safety approval.

2, Box type provides the identical outer appearance.

3, High insulation resistance, long life due to self-healing effect.

4, Very low loss at high frequency, suitable for high current.

5, Withstanding2.5kv impulse voltage, class X2.

6, As an across-the-line type noise suppression capacitor, and suitable for AC purpose.

Application:

LED lighting, Color TV, Audio device, Household applicance and so on.
