Nominal Capacitance 10uf 400v Electrolytic Capacitor Low Impedance Radial Capacitor CD263

Ask Lasest Price
Brand Name :	WS
Model Number :	WS-Ecap-CD263
Certification :	SGS
Price :	Negotiation
Payment Terms :	T/T, Western Union,Paypal
Supply Ability :	1000000pcs/day
Delivery Time :	3-5 work days

Add to Cart

Product Details
Company Profile

Nominal Capacitance 10uf 400v Electrolytic Capacitor Low Impedance Radial Capacitor CD263

10uF / 400V Low impedance radial Aluminum Electrolytic Capacitor CD263

Product Description:
Key Specifications/Special Features:
C: Nominal capacitance (uF
V: Rated voltage (V)
Dissipation factor (25 degrees Celsius, 120Hz): And shall not exceed the values shown
In the table of standard ratings
Temperature stability (120Hz): Capacitance change
10 to 100V DC: Capacitance at -40 degrees Celsius shall not be less than 60% of the
25 degrees Celsius value
160 to 400V DC: Capacitance at -25 degrees Celsius shall not be less than 70% of
The 25 degrees Celsius value
Load life (+85 degrees Celsius):
Time: 2, 000 hours
Leakage current: Not more than the specified value
Capacitance change: Within + (-) 20% of the initial value
Dissipation factor: Not more than 200% of the specified value
Shelf life (+85 degrees Celsius):
Time: 2, 000 hours
Leakage current: Not more than the specified value
Capacitance change: Within + (-) 20% of the initial value
Dissipation factor: Not more than 200% of the specified value
After test: UR to be applied for 60 minutes, 24 to 48 hours before measurement

Features:

Type	CD263
Capacitance range	0.47uF~15000uF
Rated Voltage	6.3-100V 160-450V
Working temperature	-40~+105 C
Capacitance tolerance	+/-20%(120Hz +20C)
Leakage current	I≤ 0.02(uA) (at 20, after 2 minutes)
Dissipation factor(120Hz +20)	0.35~0.12
Temperature Characteristics(lmpedance ratio at 120Hz)	8-30
Load life	After applying rated voltage for 2000 hours at +85 and then resumed 16 hours: Capacitance change: +/-25%.

Application:

Radio,DVD, VCD, Air conditioners, washing machines, energy-saving lamps , Led power etc .
