SMD Power Inductor / WS-LBS Series / Magnetic Shielded Wire Wound /
Delivery Fast
SPECIFICATIONS:
Inductance Range:1uH~2000uH
Rated Current : 0.1A~13A(Max)
DCR : 0.013~7.9 Ω (Max)
Operating temperature range : –40 to +85°C
Storage temperature range: –10 to +40°C
| Inductance Range | 1uH~2000uH |
| Rated Current | 0.1-13A |
| DCR | 0.0013~7.9Ω (Max) |
FEATURES:
Low profile
High saturation current
Magnetic shielded
SMT type
APPLICATIONS:
Power supply for VTRs
DC/DC converters etc.
Portable communication equipment
Notebook Computer
LCD television
Primary advantage:
1. Professional and Experienced engineer
2. Qualified material competative price
3. Prompt Delivery anGood after-sale service
Why Choose us:
1. High quality and best services.
2. We have RoHS and REACH, CQC certification.
3. Our company has pass the ISO9001:2008
Payment and Shipping:
1, Lead time about 3~5 days.
2, Payment: T/T; Western union; Paypal .
3, Shipping: by DHL, Fedex, TNT, UPS, EMS ect
| Part Number | L (μH) | Tolerance | Test Freq. | DCR(Ω)Max | Isat( A) |
| LBS6028-1R0NT | 1 | 30% | 1kHz | 0.025 | 3. 00 |
| LBS6028-6R8NT | 6.8 | 30% | 1kHz | 0.065 | 1. 50 |
| LBS6028- 100MT | 10 | 20% | 1kHz | 0.115 | 1. 30 |
| LBS6028- 150MT | 15 | 20% | 1kHz | 0.15 | 1. 00 |
| LBS6028- 220MT | 22 | 20% | 1kHz | 0.205 | 0. 77 |
| LBS6028- 330MT | 33 | 20% | 1kHz | 0.3 | 0. 69 |
| LBS6028- 470MT | 47 | 20% | 1kHz | 0.41 | 0. 59 |
| LBS6028- 680MT | 68 | 20% | 1kHz | 0.575 | 0. 50 |
| LBS6028- 101MT | 100 | 20% | 1kHz | 0.95 | 0. 42 |
| LBS6028- 561MT | 560 | 20% | 1kHz | 5.1 | 0. 12 |
| LBS7 030-1R0 NT | 1 .0 | 20% | 1kHz | 0.027 | 5 |
| LBS7 030-4R7 NT | 4 .7 | 20% | 1kHz | 0.052 | 1.6 |
| LBS7 030-6R8 NT | 6 .8 | 20% | 1kHz | 0.065 | 1.5 |
| LBS7 030-100 MT | 10 | 20% | 1kHz | 0.082 | 1.3 |
| LBS7 030-150 MT | 15 | 20% | 1kHz | 0.114 | 1 |
| LBS7 030-220 MT | 22 | 20% | 1kHz | 0.183 | 0.86 |
| LBS7 030-330 MT | 33 | 20% | 1kHz | 0.235 | 0.65 |
| LBS7 030-470 MT | 47 | 20% | 1kHz | 0.35 | 0.57 |
| LBS7 030-680 MT | 68 | 20% | 1kHz | 0.53 | 0.49 |
| LBS7 030-101 MT | 1 00 | 20% | 1kHz | 0.843 | 0.4 |
| LBS7 030-151 MT | 1 50 | 20% | 1kHz | 1.39 | 0.32 |
| LBS7 030-221 MT | 2 20 | 20% | 1kHz | 1.6 | 0.26 |
| LBS7 030-331 MT | 3 30 | 20% | 1kHz | 2.8 | 0.22 |
| LBS7 030-471 MT | 4 70 | 20% | 1kHz | 3.5 | 0.18 |
| LBS7 030-681 MT | 6 80 | 20% | 1kHz | 4.3 | 0.16 |
| LBS7 030-102 MT | 10 00 | 20% | 1kHz | 7.9 | 0.12 |
| Isat: Saturation Current, the current when the inductance becomes
10% lower than its init ial value. |
|
