Unshielded Magnetic SMD Power Inductor , WSBTSF Surface Mount Inductor For Laptop

FEATURES:

Various high power inductors are superior to be high saturation for surface mounting .

Inductance Range: 1uH - 1000uH
Rated Current : 0.1A~20A(Max)

DCR : 0.1~10 Ω (Max)

Low profile
High saturation current

Magnetic shielded
SMT type
Large permissible D.C. current and low D.C. resistance

PART NUMBERING SYSTEM:
WSBTSF - 3316 - 100 - K - R
(1 ) (2) (3) (4) (5)
1 Series Name
2 Dimensions
3 Inductance 1R0＝1.0 uH.100＝10uH.101＝100uH.
4 Tolerance J＝±5%, K＝±10%, L＝±15%, M＝±20%, P＝±25%, N＝±30%
5 Packing code R: Tape&Reel B: In Bulk

APPLICATIONS:

(1) Video cameras.

(2) Portable VCRs.

(3) Audio equipments.

(4) TV tunners.

(5) Switching power supplies.

(6) Other circuits of consideration aganist radiation
